Much of the film and television industry has, or is in the process of, transitioning from 1.5G-SDI to 3G-SDI. Bluefish444 SDI and HDMI Professional video cards capture and playback these video formats at the highest quality.
Epoch | 4K Neutron | Epoch | 4K Neutron LP | Epoch | 4K Supernova S+ | Epoch | 4K Supernova S+ EX | Epoch | 4K Supernova | KRONOS K8 [R] | KRONOS K8 | |
---|---|---|---|---|---|---|---|
Part number | EB3006C | EB3006F | EB3005M | EB3005MRL | EB3004A | K4001 | K4002 |
MSRP (USD) | $2,695 Find a Reseller |
$2,795 Find a Reseller |
$4,595 Find a Reseller |
$4,870 Find a Reseller |
$3,995 Find a Reseller |
$4,495 Find a Reseller |
$5,495 Find a Reseller |
Max number of bi-directional SDI I/Os | 3 | 3 | 4 | 4 | 4 | 8 | 8 |
SD-SDI/1.5G HD-SDI/Dual Link 1.5G (4:2:2:4/4:4:4:4) | YES | YES | YES | YES | YES | YES | YES |
3G-SDI (Level A+B) | 3 | 3 | 3 | 3 | 3 | 4 | 8 |
Dual Link 3G (Level A+B) | YES | YES | YES | YES | YES | YES | YES |
Quad Link 1.5/Quad Link 3G (Level A+B) | NO | NO | YES* | YES* | YES* | YES | YES |
2K/HD/SD HDMI (OUTPUT) | YES | YES | NO | NO | NO | NO | NO |
4K HDMI (OUTPUT) | YES | YES | NO | NO | NO | NO | NO |
Full-height, 2/3-length PCIe | NO | NO | YES | YES | NO | NO | NO |
Full-height, Half-length PCIe | YES | NO | NO | NO | NO | YES | YES |
Full-height, Full-length PCIe | NO | NO | NO | NO | YES | NO | NO |
Low-profile, Half-length PCIe | NO | YES | NO | NO | NO | NO | NO |
Dedicated AUX Reference INPUT | YES^ | NO | NO | NO | NO | NO | NO |
Reference INPUT BNC | YES | YES | YES | YES | YES | YES | YES |
Reference OUTPUT BNC | NO | NO | NO | NO | NO | YES | YES |
SDI monitor BNC | YES^ | NO | YES | YES | NO | NO | NO |
LTC I/O | NO | NO | NO | YES | NO | YES | YES |
Breakout cable 8 x AES audio I/O, 2 x analogue audio OUTPUT, RS-422, Auxiliary Reference INPUT |
YES^ | YES^ | NO | YES | NO | NO | NO |
Stem port Options for AES audio, stereo analogue sound and RS-422, or AES audio, LTC I/O and RS-422 |
NO | NO | NO | NO | NO | YES | YES |
IngeSTore | YES | YES | YES | YES | YES | YES | YES |
*Not able to support 4 independent video channels at 3G. ^Dependent on configuration. Please see the Optional Connectivity section of the Epoch | 4K Neutron Features page for more information on available options. #Available on EX version. Please see the Connectivity section of the Epoch | 4K Supernova S+ page for more information.
