Epoch | 4K Neutron Range
A tiny star radiating immense power.
The Epoch | Neutron range contains solutions for SD - HD, 3G - 4K and 4K+ workflows. Offering up 3 HD/SD-SDI or 3G/HD/SD-SDI inputs or outputs alongside 4K/UHD or 2K/HD HDMI monitoring, the Neutron range can cater for current and future requirements. For extra connectivity and up to 4K/UHD 60p I/O, multiple Epoch | 4K Neutron cards can be used together to suit your needs.
At a glance
| Epoch | Neutron | Epoch | Neutron LP | Epoch | 4K Neutron | Epoch | 4K Neutron LP | |||
|---|---|---|---|---|---|---|
| Part Number | EB3007B | EB3007C | EB3007F | EB3006B | EB3006C | EB3006F |
| MSRP (USD) | $1,995 Find a Reseller |
$2,095 Find a Reseller |
$1,995 Find a Reseller |
$2,695 Find a Reseller |
$2,795 Find a Reseller |
$2,695 Find a Reseller |
| Max number of bi-directional SDI I/Os | 3 | 3 | 3 | 3 | ||
| SD-SDI/1.5G HD-SDI/Dual Link 1.5G (4:2:2:4/4:4:4:4) | YES | YES | YES | YES | ||
| 3G-SDI (Level A+B)/Dual Link 3G (Level A+B) | NO | NO | YES | YES | ||
| Quad Link 1.5/Quad Link 3G (Level A+B) | NO | NO | NO | NO | ||
| 2K/HD/SD HDMI (OUTPUT) | YES | YES | YES | YES | ||
| 4K HDMI (OUTPUT) | NO | NO | YES | YES | ||
| Full-height, Half-length PCIe | YES | NO | YES | NO | ||
| Low-profile, Half-length PCIe | NO | YES | NO | YES | ||
| IngeSTore | YES | YES | YES | YES | ||
| Reference INPUT BNC | YES | YES | YES | YES | ||
| Dedicated AUX Reference INPUT | YES* | NO | NO | YES* | NO | NO |
| Breakout Cable 8 x AES audio I/O, 2 x analogue audio OUTPUT, RS-422, auxiliary Reference INPUT |
YES* | YES* | YES* | YES* | YES* | YES* |
*Dependant on configuration. Please see the Optional Connectivity section of the Epoch | Neutron Features page or the Epoch | 4K Neutron Features page for more information on available options.
